Environmental requirements
Transport:
Temperature ‐20°C ‐ +60°C (‐4°F ‐ +140°F)
Relative humidity 10 ‐ 90% RH (non-condensing)
Air pressure 700 ‐ 1060 hPa
Storage:
Temperature ‐10°C ‐ +50°C (+14°F ‐ +122°F)
Relative humidity 10 ‐ 90% RH (non-condensing)
Air pressure 700 ‐ 1060 hPa
Operating:
Temperature +10°C ‐ +35°C (+50°F ‐ +95°F)
Relative humidity 10 ‐ 90% RH (non-condensing)
Air pressure 800 ‐ 1060 hPa
Max. altitude 2000 m (1.25 miles)
Image properties
ProCeph:
Flat panel pixel size 139 µm
Flat panel active surface 302 x 249 mm (11.89 x 9.80 in.)
3D:
Flat panel pixel size Planmeca Viso G5: 127 μm
Planmeca Viso G7: 139 µm
Flat panel active surface Planmeca Viso G5: 157.5 x 157.5 mm (6.20 x
6.20 in.)
Planmeca Viso G7: 299.7 x 246.3 mm (11.80 x
9.70 in.)
Pan (SmartPan):
Flat panel pixel size Planmeca Viso G5: 127 μm
Planmeca Viso G7: 139 µm
Flat panel active surface 8.9 x 167 mm (0,35 x 6,6 in.)
Operating requirements for ProFace program
Optimum colour temperature Approx. 6500 Kelvin
Even and uniform lighting
No bright lights
Original manufacturer
Planmeca Oy, Asentajankatu 6, FIN-00880, Helsinki, Finland
Phone: +358 20 7795 500, Fax: +358 20 7795 555, www.planmeca.com
19 Technical specifications
User's manual Planmeca Viso 105
