Plockmatic BLM 50

To Next Page

To Previous Page

Rotate Crease Trim Module, continued

1. Exit section “D”

2. Bleed trimmer circular knives

3. Infeed Section “A”

4. Main switch

5. Counter

31 4

Parts that are important for setup, adjustments, troubleshooting or maintenance are high-

lighted below.
