Plockmatic BLM 50 - Cover Feeder Misfeed Clearing; Vertical Transport Area Misfeeds

67
5
[A]
[B]
NOTE:
In case of a cover feeding jam/error, it is difcult to remove a stuck cover due to the very strong
separation nip. Removing the stack of sheets and then lifting the jam clearance bafe is the
easiest way to remove a cover that is stuck.
1 Open the top cover [A].
2 Lift the jam clearance bafe [B].
3 Remove the misfed sheet.
4 Put the jam clearance bafe back in normal position.
Clearing misfeed(s) in vertical transport area
Cover Feeder
