Clearing misfeed(s)
Booklet Maker
Inside the Booklet Maker
To clear a misfeed indicated in Area B3
1 Open the top cover.
2 Close top cover.
To clear a misfeed indicated in Area B2
1 Open the top cover.
2 Close top cover.
If system does not purge, open top cover and
remove misfed sheets manually.
If misfeed condition remains:
1 Switch off the main power.
2 Switch on the main power.
To clear a misfeed indicated in Area B1
1 Open the top cover.
2 Remove misfed sheets.
3 Close the top cover.
