WARNING

Do not place your ngers inside the knife guards.

Doing so may result in injury.

Cleaning the paper path transportation nip rollers (12x), continued

Cleaning the xing rollers (3x)

Also clean the idling rollers

Knife guards

Fixing rollers

continued on next

page

Nip rollers

Nip rollers (2x)
