Plockmatic BLM 50 - BST4000-1 Belt Stacker Module

30
1 Control panel
2 Conveyor belt
2
1
1
2
3
4
5
6
7
8
9
BST4000-1 Belt Stacker Module
The BST4000-1 High Capacity Belt Stacker Module is an option available for the
Plockmatic BLM50 or BLM35 Production Booklet Maker System. The stacker can be
congured in a straight line after the booklet maker system or at a 90 degree angle.
Parts that are important for setup, adjustments, troubleshooting or maintenance are high-
lighted below.
1 Stacking tray
2 Conveyor belt
3 COM-cable
4 Side guides
5 Front end side guide adjustment knobs
6 Leg assembly
7 Control panel box
8 Height adjustment knobs (two on each leg)
9 Rear end side guide adjustment knobs (underneath)
