Plockmatic BLM 50 - Cover Feeder Module; Trimmer Module

99
8
Cover Feeder Module
Specications Remarks
Maximum Speed Same as BLM35/50 Booklet Maker A3/11x17” or bigger paper
sizes, need two sheet sets as
inlet at least
Standard Paper Sizes Same as BLM35/50 Booklet Maker
Paper Weight (Minimum) 64gsm / 16lb Bond
Paper Weight (Maximum) 250gsm / 67lb Bond
Cover Feeder Capacity 20mm (app. 200 sheets of 80gsm paper)
13/16” (app. 200 sheets of 20lb Bond paper)
Off-line Use Possible (Together with Booklet maker)
Weight 8kg / 17.6lb or less
Dimensions (W x D x H) 310 x 190 x 530mm / 12.2 x 7.5 x 20.9” The Cover Feeder dimensions
are included in the Booklet
Maker dimensions and will not
add anything more to the space.
Power Source From BLM35/50 Booklet Maker
Trimmer Module
Specications Remarks
Speed 1800 sets per hour
Standard Paper Sizes Same as BLM35/50 Booklet Maker Custom sizes are available
Default trim length 4.5mm / (11/64”) Adjustable in 0.5mm (0.004”) steps
Minimum trimming 1mm / (0.0394”)* Rec. min trim is 2,5mm (0.098”)
Maximum trimming 16mm (
5
/
8
”) per cut Possible to trim down to 105mm
(4
9
/
64
”). Trim larger than 16mm (
5
/
8
”)
will cause trimmer to make multiple
cycles. This reduces system speed
in some applications. Multiple cuts
also affect lifetime.
Paper Weight (Min / Max) Same as BLM35/50 Booklet Maker
Paper Weight (Max) Same as BLM35/50 Booklet Maker
Input / Output Sheets Same as BLM35/50 Booklet Maker
Off-line Use Possible (Together with Booklet maker)
Weight 73kg / 160.8lb or less
Dimensions (W x D x H) 360 x 1100 x 730mm / 14.2 x 43.3 x 28.8” Incl. cable protector**
Power Source From BLM35/50 Booklet Maker
* When trimming SRA3 (450mm) Booklets minimum trimming is 5mm, when trimming 18” Booklets mini-
mum trimming is 9mm / 0.35”.
**Cable protector adds 90mm / 3.5” to depth.
