BookFold Module, continued
1 Upper feed belt release latch
2 Lower feed belts
3 Upper feed belts
BookFold Module, top view,
non operator side upper feed
belts lifted up
NOTE:
Upper feed belt on
operator side cannot
be lifted fully
Parts that are important for setup, adjustments, troubleshooting or maintenance are high-
lighted below.
