2.31
MAINTENANCE
2
Winch Operation (If Equipped)
This information is for Sportsman models equipped with a
winch in the front.
Winch Handlebar Control
s
The winch is located in the front bumper area.
The mini-rocker (IN/OUT) control controls the direction of the
cable for the winch. IN pulls the cable into the winch and OUT
feeds the cable out of the winch.
Winch Control
The winch control located on the side of the winch gives the
operator easy access to switch between ENGAGED and
FREESPOOL.
When the winch is ENGAGED, the winch only allows the cable
to be pulled IN or released OUT via the mini-rocker switch on
the handlebar.
When the winch is FREESPOOL, the winch allows the cable to
be pulled out freely.
NOTE: The switch on the handlebar does not have to be in
the OUT position.
FREESPOOL
L
ENGAGE
