7.40
FINAL DRIVE
Exploded View
Rear Gearcase
A-arm bolts
Rear Drive Axle
A-arm bolts
Nuts
Bushings
Lower A-arm
Carrier Bolt
Shaft
Bushings
Snap Ring
Coil
30 ft. lbs.
(41 Nm)
Shock
Shaft
Bearing
Bushings
30 ft. lbs.
(41 Nm)
Bushings
Shaft
Upper A-arm
Caliper
18 ft. lbs.
(24 Nm)
30 ft. lbs.
(41 Nm)
