Polycom Vortex EF2280 User Manual

F01AGC*2
Toggle AGC state on input channels 1-
8.
F01AGC*abcdefgh, where a-h are each 0 or 1 depending
on the current state of the AGC for each of the eight input
channels.
F01AGC*?
Query AGC state on input channels 1-
8.
F01AGC*abcdefgh, where a-h are each 0 or 1 depending
on the current state of the AGC for each of the eight input
channels.
8.5. AGCMAX -- Set Maximum Allowed Mic/Line Input AGC Gain
This command sets the maximum gain that the AGC can apply on input channels 1-8 . For example, if AGCMAX is
set to 10, then the AGC for that channel can apply a maximum of 10 dB of gain to the input signal.
This command is a channel integer command. See
Section 6.3 and Section 6.2 for more information on this type
of command. The minimum and maximum values for this command are 0 and 15, respectively.
This command is saved to non-volatile memory only as part of a preset. The state of this command will be
restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example Description Status Message
F01AGCMAX13
Set AGC maximum gain on
input channel 1 to 3 dB.
F01AGCMAX13
F01AGCMAX1?
Query the AGC maximum
gain on input channel 1 .
F01AGCMAX1x where x is a number between 0 and 15,
depending on the current setting of the AGC maximum
gain on input channel 1 .
F01AGCMAX*6
Set AGC maximum gain on
input channels 1-8 to 6 dB.
F01AGCMAX*èèèèèèèè
F01AGCMAX*ääääìììì
Set AGC maximum gain on
input channels 1-4 to 0 dB
and AGC maximum gain on
input channels 5-8 to 9 dB.
F01AGCMAX*ääääìììì
F01AGCMAX*?
Query AGC maximum gain
on input channels 1-8.
F01AGCMAX*abcdefgh, wherea a-h are each between
ä and É, depending on the current setting of the AGC
maximum gain for each of the eight input channels.
8.6. AGCMIN -- Set Minimum Allowed Mic/Line Input AGC Gain
This command sets the minimum gain that the AGC can apply on input channels 1-8 . For example, if AGCMIN is
set to -10, then the AGC for that channel can apply a minimum of -10 dB of gain to the input signal.
This command is a channel integer command. See
Section 6.3 and Section 6.2 for more information on this type
of command. The minimum and maximum values for this command are -15 and 0, respectively.
This command is saved to non-volatile memory only as part of a preset. The state of this command will be
restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example Description Status Message
F01AGCMIN1-3
Set AGC minimum gain on
input channel 1 to -3 dB.
F01AGCMIN1-3

Polycom Vortex EF2280 Specifications

General

Rack capacity	1U
Frequency range	20 - 20000 Hz
Cancellation span	270 ms
Echo cancellation	65 dB
Phantom power	48 V
Nominal input level	0 dB
Output gain	-100 - 20 dB
Output impedance	33 Ω
Maximum output amplitude	23 dB
RS-232 ports	1
Audio connections	2 x 3.5mm
Parallel ports quantity	2
Input voltage	110 - 240 V
Output current	20 mA
Output voltage	5 V
Input frequency	47/63 Hz
Power consumption (typical)	30 W
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	1800 g
Dimensions (WxDxH)	483 x 244 x 45 mm
