Polycom Vortex EF2280 User Manual

F01AGCMIN1?
Query the AGC minimum
gain on input channel 1 .
F01AGCMIN1x where x is a number between -15 and
0, depending on the current setting of the AGC
minimum gain on input channel 1 .
F01AGCMIN*-6
Set AGC minimum gain on
input channels 1-8 to -6 dB.
F01AGCMIN*~~~~~~~~
F01AGCMIN*ääääüüüü
Set AGC minimum gain on
input channels 1-4 to 0 dB
and AGC minimum gain on
input channels 5-8 to -3 dB.
F01AGCMIN*ääääüüüü
F01AGCMIN*?
Query AGC minimum gain on
input channels 1-8.
F01AGCMIN*abcdefgh, where a-h are each between
u and ä, depending on the current setting of the AGC
minimum gain for each of the eight input channels.
8.7. AGCRATE -- Set Ramp Rate of Mic/Line Input AGC
This command sets or queries the maximum rate at which the AGC can increase or decrease the gain of the
signals on input channels 1-8 . The ramp rate is expressed in dB/sec.
This command is a channel integer command. See
Section 6.3 and Section 6.2 for more information on this type
of command. The minimum and maximum values for this command are 1 and 5, respectively.
This command is saved to non-volatile memory only as part of a preset. The state of this command will be
restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example Description Status Message
F01AGCRATE13
Set AGC ramp rate on input
channel 1 to 3 dB/sec.
F01AGCRATE13
F01AGCRATE1?
Query the AGC ramp rate
on input channel 1 .
F01AGCRATE1x where x is a number between 1 and 5,
depending on the current setting of the AGC ramp rate
on input channel 1 .
F01AGCRATE*5
Set AGC ramp rate on input
channels 1-8 to 5 dB/sec.
F01AGCRATE*ëëëëëëëë
F01AGCRATE*ààààêêêê
Set AGC ramp rate on input
channels 1-4 to 1 dB/sec
and AGC ramp rate on
input channels 5-8 to 4
dB/sec.
F01AGCRATE*ààààêêêê
F01AGCRATE*?
Query AGC ramp rate on
input channels 1-8.
F01AGCRATE*abcdefgh, where a-h are each between
à and ë, depending on the current setting of the AGC
ramp rate for each of the eight input channels.
8.8. AMASGN -- Assign Inputs to an Automixer
This command is used to assign one of the mic/line inputs (1-8) to an internal automixers. Setting AMASGN to 0
for a given input channel corresponds to no automixer, 1 corresponds to Automixer #1 , and 2 corresponds to
automixer #2.
An AMASGN command usually removes a microphone from one automixer and adds it to another. If the
microphone is removed from an automixer where it was assigned as the "Last Mic On" and list mic mode

Polycom Vortex EF2280 Specifications

General

Rack capacity	1U
Frequency range	20 - 20000 Hz
Cancellation span	270 ms
Echo cancellation	65 dB
Phantom power	48 V
Nominal input level	0 dB
Output gain	-100 - 20 dB
Output impedance	33 Ω
Maximum output amplitude	23 dB
RS-232 ports	1
Audio connections	2 x 3.5mm
Parallel ports quantity	2
Input voltage	110 - 240 V
Output current	20 mA
Output voltage	5 V
Input frequency	47/63 Hz
Power consumption (typical)	30 W
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	1800 g
Dimensions (WxDxH)	483 x 244 x 45 mm
