Polycom Vortex EF2280 User Manual

F01MGAINA,W,?
Query gain from
input A to W
Bus output.
F01MGAINA,W,x , where x is the current value of
the crosspoint gain. If the crosspoint gain was set
to -12 dB before this command, then the status
message would be F01MGAINA,W,-12 .
F01MGAINWB0,WM0,-3
Set crosspoint
gain in EF Bus
submatrix on
crosspoint that
routes the W
bus signal from
the device at
ID0 (WB0) to W
submatrix
output 0 (WM0).
F01MGAINWB0,WM0,-3
F01MGAIN1,*,ääääääää{{{{ääÇÇÇÇ
Set all
crosspoint gains
for input
channel 1. Set
the gain to
outputs 1-8 to 0
dB (ä), the gain
to outputs A-D
to -9 dB ({), the
gain to AEC
reference 1 and
2 to 0 dB (ä),
and the gain to
bus outputs W,
X, Y, and Z to -3
dB (Ç).
F01MGAIN1,*,ääääääää{{{{ääÇÇÇÇ
F01MGAINB,*,-3
Set all
crosspoint gains
for input
channel B to -3
dB.
F01MGAINB,*,ÇÇÇÇÇÇÇÇÇÇÇÇÇÇÇÇÇÇ
F01MGAINB,*,>12
Increase the
gain for all
crosspoints of
input channel B
by 12 dB.
F01MGAINB,*,abcdefghijklmnopqr , where
the value of each of letters (a, b, etc.) depends on
the current state of each of the crosspoint gains. If
this command was issued after the example above,
then the status message would be
F01MGAINB,*,èèèèèèèèèèèèèèèèèè
F01MGAINB,*,?
Query the gains
for all
crosspoints of
input channel B
.
F01MGAINB,*,abcdefghijklmnopqr , where
the value of each of letters (a, b, etc.) depends on
the current state of each of the crosspoint gains. If
this command was issued after the example above,
then the status message would be
F01MGAINB,*,èèèèèèèèèèèèèèèèèè
8.89. MGATE -- Select Gated or Ungated Microphone Signal in
Matrix
For each crosspoint of the microphone input channels of the main matrix, the microphone signals can be taken

Polycom Vortex EF2280 Specifications

General

Rack capacity	1U
Frequency range	20 - 20000 Hz
Cancellation span	270 ms
Echo cancellation	65 dB
Phantom power	48 V
Nominal input level	0 dB
Output gain	-100 - 20 dB
Output impedance	33 Ω
Maximum output amplitude	23 dB
RS-232 ports	1
Audio connections	2 x 3.5mm
Parallel ports quantity	2
Input voltage	110 - 240 V
Output current	20 mA
Output voltage	5 V
Input frequency	47/63 Hz
Power consumption (typical)	30 W
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	1800 g
Dimensions (WxDxH)	483 x 244 x 45 mm
