Polycom Vortex EF2280 User Manual

F01PHANTOM*2
Toggle phantom power for
input channels 1-8.
F01PHANTOM*abcdefgh where a-h are each 0 or 1
depending on the current state of phantom power for
the corresponding input channel.
F01PHANTOM*?
Query status of phantom
power for input channels 1-
8.
F01PHANTOM*abcdefgh where a-h are each 0 or 1
depending on the current state of phantom power for
the corresponding input channel.
F01PHANTOM*11110000
Enable phantom power for
inputs 1-4 and disable
phantom power for inputs 5-
8.
F01PHANTOM*11110000
8.118. PING -- See Which Devices Are Present
When any Vortex device receives this command, it responds with a PONG status message. This is typically used
by the host program to determine the types and IDs of all linked devices. When used in this manner, wildcard
characters are usually given for the device type and ID so that all connected devices will respond.
In the following example, it is assumed that there are two EF2280's (device IDs 0 and 1), two EF2241's (device
IDs 2 and 3), two EF2211's (device IDs 4 and 5), two EF2210's (device ID's 6 and 7), and two EF2201's (device
ID's 0 and 1) linked together via EF Bus.
Example Description Status Message
***PING
Ping all connected device to determine the number, type, and ID of the connected
devices.
F00PONG
F01PONG
B02PONG
B03PONG
S04PONG
S05PONG
Q06PONG
Q07PONG
T00PONG
T01PONG
8.119. PRESETK -- Delete One or All Presets
This command kills (deletes) the specified preset. If a wildcard character (*) is used to specify the preset, then
all presets are deleted.
If an attempt is made to delete one of the factory presets (in the range 0-15), the PRESETK command will fail
and generate an ERROR#071. This is because the factory presets are read-only, thus the cannot be changed or
deleted.
This command is saved to global non-volatile memory and is not part of a preset. Its value is saved each time it
is changed. It will retain its value after power-down. Since this command writes to non-volatile memory, there
will be a delay before an acknowledgment is returned.
Example Description Status Message

Polycom Vortex EF2280 Specifications

General

Rack capacity	1U
Frequency range	20 - 20000 Hz
Cancellation span	270 ms
Echo cancellation	65 dB
Phantom power	48 V
Nominal input level	0 dB
Output gain	-100 - 20 dB
Output impedance	33 Ω
Maximum output amplitude	23 dB
RS-232 ports	1
Audio connections	2 x 3.5mm
Parallel ports quantity	2
Input voltage	110 - 240 V
Output current	20 mA
Output voltage	5 V
Input frequency	47/63 Hz
Power consumption (typical)	30 W
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	1800 g
Dimensions (WxDxH)	483 x 244 x 45 mm
