Polycom Vortex EF2280 User Manual

F01PEQOG3,2,-20
Set the gain of the parametric EQ on
output 3 , band 2 to -20 dB.
F01PEQOG3,2,-20
F01PEQOGB,1,?
Query current gain setting of
parametric EQ on output B , band 1.
F01PEQOGB,1,g , where g is the current setting
of the gain parameter for the parametric EQ on
output B , band 1. If the gain parameter of this
filter is set to the same value given in the example
above, then the status message will be
F01PEQOGB,1,-20 .
8.115. PEQOS -- Set Slope Parameter for Specified Parametric EQ
Output Stage
This command sets or queries the slope parameter (in dB per octave) for the parametric equalizer (EQ) filters on
output channels 1-8 and A-D . Each channel has five bands of parametric EQ that can be independently
controlled.
For the Linkwitz-Riley filters, the slope can either be 12 or 24 (dB/Octave).For the low shelf and high shelf filters,
the minimum value for the slope parameter is 1, and the maximum value is 1.2 times the current value of the
gain parameter. See the
PEQIG command for information on the gain parameter.
This command has the same format and restrictions as the
PEQOA command except that only one parameter, the
slope, is specified instead of all the parameters. See the
PEQOA command for more information. To set the slope
parameter for an input parametric EQ filter, use the
PEQIS command. To set all the parameters for an input
parametric EQ filter, use the
PEQIA command.
This command is saved to non-volatile memory only as part of a preset. The state of this command will be
restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example Description Status Message
F01PEQOS3,2,1
Set the slope of the parametric EQ on
output 3 , band 2 to 1 dB per octave.
F01PEQOS3,2,1
F01PEQOSB,1,?
Query current slope setting of
parametric EQ on output B , band 1.
F01PEQOSB,1,s , where s is the current setting of
the slope parameter for the parametric EQ on output
B , band 1. If the slope parameter of this filter is set
to the same value given in the example above, then
the status message will be F01PEQOSB,1,1 .
8.116. PEQOT -- Set Type Parameter for Specified Parametric EQ
Output Stage
This command sets or queries the type parameter for the parametric equalizer (EQ) filters on output channels 1-
8 and A-D . Each channel has five bands of parametric EQ that can be independently controlled.
The type parameter specifies what type of filter is executed for the specified band of the specified output
channel. The different filter types and their corresponding values are shown in the table below.
Filter Type Value of Type Parameter
Parametric 1

Polycom Vortex EF2280 Specifications

General

Rack capacity	1U
Frequency range	20 - 20000 Hz
Cancellation span	270 ms
Echo cancellation	65 dB
Phantom power	48 V
Nominal input level	0 dB
Output gain	-100 - 20 dB
Output impedance	33 Ω
Maximum output amplitude	23 dB
RS-232 ports	1
Audio connections	2 x 3.5mm
Parallel ports quantity	2
Input voltage	110 - 240 V
Output current	20 mA
Output voltage	5 V
Input frequency	47/63 Hz
Power consumption (typical)	30 W
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	1800 g
Dimensions (WxDxH)	483 x 244 x 45 mm
