Polycom Vortex EF2280 User Manual

Example Description Status Message
F01AMGATEC10
Configure microphone input
1 for normal gating.
F01AMGATEC10
F01AMGATEC21
Configure microphone input
2 to be forced on.
F01AMGATEC21
F01AMGATEC32
Configure microphone input
3 to be forced off.
F01AMGATEC32
F01AMGATEC3?
Query current gating control
mode for microphone input
3 .
F01AMGATEC3x , where x is 0, 1, or 2 depending on
the current gating control mode setting for microphone
input 3 .
F01AMGATEC*0
Configure microphone
inputs 1-8 for normal
gating.
F01AMGATEC*ääääääää
F01AMGATEC*äääàààåå
Configure microphone
inputs 1-3 for normal
gating, microphone inputs 4-
6 to be forced on, and
microphone inputs 7-8 to be
forced off.
F01AMGATEC*äääàààåå
F01AMGATEC*?
Query gating control mode
for all microphone inputs.
F01AMGATEC*abcdefgh , where a-h are each ä, à,
or å depending on the current setting of the gating
control mode for each channel. If this command is
issued after the example above, then the status
message will be F01AMGATEC*äääàààåå .
8.15. AMGATER -- Set Automixer Gate Ratio
This command sets the automixer gate ratio (in dB) for the specified input channel. The gate ratio is the ratio of
the speech power to noise power required to gate the microphone on. This value is only used if the input is set
to automatic gating via the
AMAUTO.
This command is a channel integer command. See
Section 6.3 and Section 6.2 for more information on this type
of command. The minimum and maximum values for this command are 0 and 100, respectively.
This command is saved to non-volatile memory only as part of a preset. The state of this command will be
restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example Description Status Message
F01AMGATER312
Set gate ratio for automatic
gating threshold to 12 dB
for input channel 3 .
F01AMGATER312
F01AMGATER3>3
Increase gate ratio for
automatic gating threshold
by 3 dB for input channel 3
.
F01AMGATER3x , where x is between 0 and 100
depending on the current setting of the gate ratio for
input channel 3 . If this command is issued after the
example above, then the status message will be
F01AMGATER315 .

Polycom Vortex EF2280 Specifications

General

Rack capacity	1U
Frequency range	20 - 20000 Hz
Cancellation span	270 ms
Echo cancellation	65 dB
Phantom power	48 V
Nominal input level	0 dB
Output gain	-100 - 20 dB
Output impedance	33 Ω
Maximum output amplitude	23 dB
RS-232 ports	1
Audio connections	2 x 3.5mm
Parallel ports quantity	2
Input voltage	110 - 240 V
Output current	20 mA
Output voltage	5 V
Input frequency	47/63 Hz
Power consumption (typical)	30 W
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	1800 g
Dimensions (WxDxH)	483 x 244 x 45 mm
