Polycom Vortex EF2280 User Manual

Low Shelf 2
High Shelf 3
Lowpass 4
Highpass 5
Linkwitz-Riley Lowpass 6
Linkwitz-Riley Highpass 7
This command has the same format and restrictions as the
PEQOA command except that only one parameter, the
filter type, is specified instead of all the parameters. See the
PEQOA command for more information. To set the
slope parameter for an input parametric EQ filter, use the
PEQIT command. To set all the parameters for an
input parametric EQ filter, use the
PEQIA command.
This command is saved to non-volatile memory only as part of a preset. The state of this command will be
restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example Description Status Message
F01PEQOT3,2,1
Set the type of the parametric EQ on
output 3 , band 2 to parametric.
F01PEQOT3,2,1
F01PEQOTB,1,?
Query current type setting of
parametric EQ on output B , band 1.
F01PEQOTB,1,t , where t is the current setting of
the type parameter for the parametric EQ on output
B , band 1. If the type parameter of this filter is set
to the same value given in the example above, then
the status message will be F01PEQOTB,1,1 .
8.117. PHANTOM -- Enable Phantom Power on Inputs 1-8
This command sets or queries the status of phantom power on each of the microphone inputs.
This command is a channel boolean command. See
Section 6.3 and Section 6.1 for more information on this type
of command.
This command is saved to non-volatile memory only as part of a preset. The state of this command will be
restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example Description Status Message
F01PHANTOM21
Enable phantom power for
input channel 2 .
F01PHANTOM21
F01PHANTOM20
Disable phantom power for
input channel 2 .
F01PHANTOM20
F01PHANTOM22
Toggle phantom power
state for input channel 2 .
F01PHANTOM2x , where x is 0 or 1 depending on the
current state of phantom power on input channel 2 .
F01PHANTOM2?
Query state of phantom
power for input channel 2 .
F01PHANTOM2x , where x is 0 or 1 depending on the
current state of phantom power on input channel 2 .
F01PHANTOM*0
Disable phantom power for
input channels 1-8.
F01PHANTOM*00000000
F01PHANTOM*1
Enable phantom power for
input channels 1-8.
F01PHANTOM*11111111

Polycom Vortex EF2280 Specifications

General

Rack capacity	1U
Frequency range	20 - 20000 Hz
Cancellation span	270 ms
Echo cancellation	65 dB
Phantom power	48 V
Nominal input level	0 dB
Output gain	-100 - 20 dB
Output impedance	33 Ω
Maximum output amplitude	23 dB
RS-232 ports	1
Audio connections	2 x 3.5mm
Parallel ports quantity	2
Input voltage	110 - 240 V
Output current	20 mA
Output voltage	5 V
Input frequency	47/63 Hz
Power consumption (typical)	30 W
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	1800 g
Dimensions (WxDxH)	483 x 244 x 45 mm
