Powtran PI8600 Series User Manual

Section V Parameter Function Table
26
Section V
The proportion of linkage running,after stop the proportion linkage slave unit with the
keyboard terminal, Rs485, the slave unit will not run the proportion liknge host unit‟s
command, it needs once again to respond to host commands through the keyboard, terminal,
RS485, or the proportion linkage host sends stop command so that slave unit could respond
to run commands.
F06
V/F boost mode
1 bit
Beeline V/F curve
0
-
0000
N
Power of 1.2 V/F curve
1
Power of1.7 powerV/Fcurve
2
Power of 2 power V/F curve
3
Define mode V/Fcurve
4
10 bit
Close automatic torque
boost
0
Automatic torqueboost
1
100 bit
VF mode 0 speed no Output
0
VF mode keep 0 speed
1
1 bit: V/F promote curve
0 Line V/F curve: Suitable for ordinary constant torque load
1 Power of 1.2 V/F curve: Appropriate torque down V/F curve, Suitable for liquid loads
2 Power of 1.7 V/F curve: Appropriate torque down V/F curve, Suitable for liquid loads
3 Power of 2 V/F curve: Torque down V/F curve, It is suitable for fans, pumps, centrifugal
load
4 Define mode V/Fcurve: Can be customized appropriate curve according to the actual
situation .
10 bit: Auto-torque boost mode
0 Close Automatic torque boost
1 Open automatic torque boost
parameters which affect automatic torque enhance :
Actual value torque component S15
b06/b19 stator resistance
F07 torque enhance value
Automatic torque enhance value = actual value of torque component * stator resistance
*torque enhance value.
100 bit: VF mode 0 speed maintain function
0 VF mode 0 Speed No Output: Output frequency is less than 0.5Hz, stop PWM output to
reduce the switching loss.
1 VF mode keep 0 speed: the output frequency is 0Hz, in accordance with the DC braking
current of starting F26, keep 0 speed.
F07
Torque boost value
0.0~30.0%
%
0.0
Y
F08
Torque boost cut-off
frequency
0.00~maximum frequency
Hz
15.00
Y
