Powtran PI8600 Series User Manual

Section V Parameter Function Table
73
Section V
100 bit: Running Segment when stop
0: Set stopping according to the parameters of stop segment.
1: Set down to the initial segment
1000 bit: Start Running Segment
0: Set down to the speed running
1: Running at the speed before the machine stopped.
100 bit=0 Set stopping according to the parameters of stop segment
1000 bit=0 running at Start Segment
STOP
RUN
T2
T1
3X
2X
1X
F51=00
T1
T2
X
1X
2X
3X
dt3'
at1'
time
output
frequency
Eg:100 bit==0 Set stopping according to the parameters of stop segment
1000 bit==1 Running at the speed before the machine stopped.
5X
X+Y=T3
3X
2X
1X
X
T2
T1
F51=01
3X
4X
Y
T4
RUN
STOP
dt3'
at3'
time
output
frequency
Eg:100 bit=1 Set down to the initial segment
1000 bit=1 Running at the speed before the machine stopped.
at1'
dt1'
3X
2X
1X
X
T2
T1
F51=10,11
1X
2X
3X
T1
T2
RUN
STOP
time
output
frequency
Note: at1＇： at the time of segment 1 acceleration time;dt1＇： at the time of segment 1
deceleration time;at3＇at the time of segment 3 acceleration time;dt3＇： at the time of segment 3
deceleration time.
H03
1 Segment speed setting
1X
Lower frequency ~ upper
frequency
Hz
3.00
Y
H04
2 Segment speed setting
2X
Lower frequency ~ upper
frequency
Hz
6.00
Y
H05
3 Segment speed setting
3X
Lower frequency ~ upper
frequency
Hz
9.00
Y
