Powtran PI8600 Series User Manual

Section V Parameter Function Table
74
Section V
H06
4 Segment speed setting
4X
Lower frequency ~ upper
frequency
Hz
12.00
Y
H07
5 Segment speed setting
5X
Lower frequency ~ upper
frequency
Hz
15.00
Y
H08
6 Segment speed setting
6X
Lower frequency ~ upper
frequency
Hz
18.00
Y
H09
7 Segment speed setting
7X
Lower frequency ~ upper
frequency
Hz
21.00
Y
H10
8 Segment speed setting
8X
Lower frequency ~ upper
frequency
Hz
24.00
Y
H11
9 Segment speed setting
9X
Lower frequency ~ upper
frequency
Hz
27.00
Y
H12
10 Segment speed setting
10X
Lower frequency ~ upper
frequency
Hz
30.00
Y
H13
11 Segment speed setting
11X
Lower frequency ~ upper
frequency
Hz
33.00
Y
H14
12 Segment speed setting
12X
Lower frequency ~ upper
frequency
Hz
36.00
Y
H15
13 Segment speed setting
13X
Lower frequency ~ upper
frequency
Hz
39.00
Y
H16
14 Segment speed setting
14X
Lower frequency ~ upper
frequency
Hz
42.00
Y
H17
15 Segment speed setting
15X
Lower frequency ~ upper
frequency
Hz
45.00
Y
Set the frequency of program running and the running frequency of 7-segment speed
respectively. short-circuit the multi-terminal command 1, 2, 3, 4 with COM combinatorially to
realized the 16-segment speed/acceleration speed.
0Xspeed is the regular running mode,setting source can be adjusted by F02,F03and other
parameters, running time is controlled by the H18.
Terminal multi-segment speed is defined as follows(shorted with COM it is ON, disconnected
then it is OFF)
Speed
Terminal
0X
1X
2X
3X
4X
5X
6X
7X
Multiterminal-speed
command 1
OFF
ON
OFF
ON
OFF
ON
OFF
ON
Multiterminal-speed
command 2
OFF
OFF
ON
ON
OFF
OFF
ON
ON
Multiterminal-speed
command 3
OFF
OFF
OFF
OFF
ON
ON
ON
ON
Multiterminal-speed
command 4
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
Speed
Terminal
8X
9X
10X
11X
12X
13X
14X
15X
Multiterminal-speed
command 1
OFF
ON
OFF
ON
OFF
ON
OFF
ON
Multiterminal-speed
command 2
OFF
OFF
ON
ON
OFF
OFF
ON
ON
Multiterminal-speed
command 3
OFF
OFF
OFF
OFF
ON
ON
ON
ON
Multiterminal-speed
ON
ON
ON
ON
ON
ON
ON
ON
