Powtran PI8600 Series User Manual

Section V Parameter Function Table
75
Section V
command 4
Acceleration and deceleration time and the direction of running
0X-7X
8X-15X
H00
10 bit
0
0X -7X Direction controlled
by parameter
8X-15X Direction controlled
by keyboard and terminal
1
0X -7X Direction controlled
by keyboard and terminal
H00
100 bit
0
0X -7Xdeceleration and
accelertation time controlled
by parameter
8X-15Xdeceleration and
accelertation time controlled
by keyboard and terminal
1
0X -7X deceleration and
accelertation time controlled
by terminal
H00
1000 bit
0
0X -7Xrunning time
controlled by paremeter
8X-15Xrunning time
controlled by terminal
1
0X -7Xrunning time
controlled by terminal
H18
0 Segment running time T0
0.0~3200.0
s
2.0
Y
H19
1 Segment running time T1
0.0~3200.0
s
2.0
Y
H20
2 Segment running time T2
0.0~3200.0
s
2.0
Y
H21
3 Segment running time T3
0.0~3200.0
s
2.0
Y
H22
4 Segment running time T4
0.0~3200.0
s
2.0
Y
H23
5 Segment running time T5
0.0~3200.0
s
2.0
Y
H24
6 Segment running time T6
0.0~3200.0
s
2.0
Y
H25
7 Segment running time T7
0.0~3200.0
s
2.0
Y
Actual running time equals to the set multi-segment running time multiples a time which is
times of speed running time, and such actual running time decided by the tens digit of H40~H46.
Please refer to H40~H46.
H26
1 Segment deceleration
time dt1
0.0~3200.0
s
10.0
Y
H27
2 Segment acceleration
time at2
0.0~3200.0
s
10.0
Y
H28
2 Segment deceleration
time dt2
0.0~3200.0
s
10.0
Y
H29
3 Segment acceleration
time at3
0.0~3200.0
s
10.0
Y
H30
3 Segment deceleration
time dt3
0.0~3200.0
s
10.0
Y
H31
4 Segment acceleration
time at4
0.0~3200.0
s
10.0
Y
H32
4 Segment deceleration
time dt4
0.0~3200.0
s
10.0
Y
H33
5 Segment acceleration
time at5
0.0~3200.0
s
10.0
Y
