Appendix D: Preventative Maintenance
Every 1 to 2 years, the following preventative Maintenance procedures should be performed. For robots
that are continuously moving 24 hours per day, 7 days a week at moderate to high speeds, a one-year
schedule is recommended. For robots with low duty cycles and low to moderate speeds, these
procedures should be performed at least once every two years.
Check List Procedure If Problem Detected
Check all belt tensions Re-tension if necessar
y
Check air harness tubing in
elbow if present, and theta axis
for an
y
wear
Replace if necessary
Replace timing belt in optional
linear axis
Typically every 6,000 hours of continuous operation
Check all joints in “free mode”
for low bearing friction and any
stickin
g
.
If a bearing is getting stiff, return to factory for bearing replacement.
Check second stage (long) Z
belt for any squeaking
If noisy, add thick grease to front and rear edge of belt if necessary.
(Shell 222 XP or similar). Z timing belt can get stiffer over time (2-3
y
ears
)
and occasionall
y
start squeakin
g
a
g
ainst pulle
y
flan
g
es.
Check if front cover is rattling If so, check .125in ID by .062in thick O rings on dowel pins in base
plate under front cover for an
y
deterioration and replace if necessar
y
.
Check Cam Followers on J2
timing belt for grease leaking or
discoloration.
Replace if necessary. Note earlier units had a 9mm wide timing belt
and later units (2014, 2015) have a 12mm wide timing and the Cam
Followers are different. See spare parts list.
Replace slip ring For units with electric gripper shipped before April 2015, replace the
slip ring. For units shipped after April 2015, replace the slip ring every
third inspection test.
