PreciseFlex_Robot
77
Software Reference
Accessing the Web Server
Many OEM customers run the PF400 using a PC to provide an application-specific operator interface. In
order to update software in the controller, and view certain error messages, it is necessary to access the
Web Server Interface embedded in the controller.
The Web Server Interface may be addressed by opening a browser (such as Internet Explorer) in a PC
that is connected to the robot via Ethernet. You must know the IP address of the robot controller. Two
common IP addresses are 192.168.0.1 and 192.168.0.10. The PC LAN interface address must be
configured correctly (for example 192.168.0.100, with subnet mask 255.255.255.0). The Web Server
Interface will come up with the window below.
