1.
Reinstall the ASL PCA board onto the ASL PCA Bracket . Securely snap the
ASL PCA board into position on the bracket.
2.
Reinstall the ASL PCA Bracket by pressing the tabs into the mounting slots on the
Power Entry Assembly Bracket .
3. Reconnect the ASL interface cable RJ11 connector, see "Wire Diagram" on
page117.
4.
Reinstall the Power Entry Assembly bracket and secure using the four #3 Phillips
fasteners. Make sure that the wire cables are not pinched or damaged during install-
ation.
5. Reinstall the hood cover, see "Hood Cover Replacement" on page88.
6. Connect the power cord and switch the ON/OFF circuit breaker ON.
7. Verify the ASL light operation:
a. Verify that the ASL light is Solid Blue. If the ALS light is Pulsing Blue, Pulsing
Yellow, or Solid Yellow, resolve the issue and reset the ASL to Solid Blue.
8. Do the Operation Verification tests (see "Operation Verification" on page24) and
return to service.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 121
6 Replacement Procedures
ASL PCA Replacement
