TIP: Avoid applying downward pressure on the bolts while removing. Pressing
down on the bolts can push the nuts out of the pivot housing .reinstall the nut into
the pivot housing if this occurs.
6. Remove the two 5/32" hex key bolt front deck fasteners. These fasteners are
attached to the left and right front GFX
1
Cushion Tinnerman clips. Retain fastener
hardware for installation.
1
Ground Effects Impact Control System: Patented treadmill design that out performs a nat-
ural running surface, absorbs high-impact movement, reduces joint stress and minimizes
fatigue and supports a solid and controlled push off.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 190
6 Replacement Procedures
Running Belt and Deck Replacement Procedure
