CONNECTOR
LOCATION
INTERFACE
DESCRIPTION
CONNECTOR/DEVICE
TYPE
HHHR Sensor Input Cable Four pin strip, keyed.
DC Input Power Two pin plug (see )
microSD mass storage .microSD memory card
Ferrite cable clamp The input power cable must be
looped thru the ferrite cable clamp.
Notes:
(1)Be careful to NOT connect the COMM Data Cable to the Ethernet input port
which can damage the CPA board.
Tools
General set of service and repair tools.
l US and Metric Hex Key set l Standard and Philips screw driver set
l DVM Multimeter l 7/16 " RF coax conn torque wrench 2.4 in-lbs (0.271 Nm)
Fastener Torque Specifications
This table provides a summary of system fasten torque specifications.
System Component Specification
RF Coax Connector 2.4 in-lbs (0.271 Nm)
Plastic Cover Screws 20 in-lbs (2.3 Nm)
Flathead Screws 25 in-lbs (2.8 Nm)
Console Fasteners 180 in-lbs (20 Nm
.
Parts
IMPORTANT: Always purchase OEM replacement parts and hardware from Precor.
If you use parts not approved by Precor, you could void the Precor Limited Warranty.
Use of parts not approved by Precor may cause injury.
Exploded View Diagram and Parts List
P82 Console 11
