CONSOLE KEY FUNCTION/DESCRIPTION
BACK softkey • Use the touchscreen BACK softkey to return to the previous
menu display.
• Continue selecting the BACK softkey to exit the service software.
PAUSE hardkey Stop a running diagnostic test.
P62 consoles
The P62 console uses a combination of touchscreen softkeys , icons, and keypad hardkeys to
select and navigate thru the service and diagnostics menus. The P62 uses the BACK keypad
button to return to the previous menu and the PAUSE hardkey to stop a running diagnostic
test.
CONSOLE KEY FUNCTION/DESCRIPTION
Touchscreen con-
trols
There are various touch sensitive softkey controls (OK. START,
STOP, BACK, etc.) and icon controls (image boxes, buttons, etc.)
used to control and operate the console. Make selection by touching
the softkey control or icon.
Scroll Up/Dwn Use your finger to select while swiping your finger Up/Dwn to scroll
through menu lists. Some menus provide an on-screen scroll bar to
scroll Up/Dwn.
BACK
• On P62 consoles, use the control keypad BACK button to go
back or return to the previous menu.
• Continue selecting the BACK hardkey to exit the service software.
P82 Console 48
7 Standard Service Menus
P62 consoles
