CARE AND MAINTENANCE
ENGINE COMPARTMENT 12148
Accessories air filter
Accessories fill valve
Accessories air tank
purge valve
FRONT SERVICE COMPARTMENT 12130
FIRE EXTINGUISHERS
Inspect fire extinguishers monthly to insure
operation in emergency situations.
On extinguishers with a pressure gauge, the
needle should be in the green or NORMAL
range. Refill or replace extinguisher if pressure is
below normal;
Check that seal on handle is intact;
Check that hose nozzle is in good condition and
the nozzle is free of obstructions;
Keep fire extinguishers clean.
FUEL FILTER/WATER SEPARATOR
The optional fuel filter/water separator installed
in the engine compartment is used to prevent
water from entering the fuel system. The water
separator should be drained periodically or when
the telltale light on the dashboard illuminates. To
drain water, loosen the drain valve below the
separator one quarter turn. Close the drain valve
when finished.
FUEL FILTER / WATER SEPARATOR 03032
BELT TENSION ADJUSTMENT
The radiator transfer fan and air conditioning
compressor are driven by V-belts.
Belt tensioning is applied through air bellows
which are adjusted by an air pressure regulating
valve mounted in the engine compartment, right
behind the belt tensioning pressure control valve.
The correct pressure of 55 psi (380 kPa) is set at
99
