TECHNICAL INFORMATION
REFER TO EATON FULLER TROUBLESHOOTING GUIDE (TRTS-0062) 07047
Eaton Transmission Fault Codes
Code Description Code Description Code Description
11 Shift Control 35 J-1939 Data Link 58
Output Shaft Speed
Sensor
12
Transmission ECU
41
Range failed to engage
61
Rail Select Motor
16
Eaton Proprietary Link
(EPL)
42 Splitter Failed to Engage 63 Gear Select Motor
17
Start Enable Relay Coil
43
Range Solenoid Valve
65
Logic Power
21 Interrupt Solenoid Coil 44
Inertia Brake Solenoid
Coil
71 Stuck Engaged
22
Lockup/Bypass Solenoid
Coil
51 Rail Select Sensor 72 Failed to Select Rail
24
Hydraulic System Fault
52
Gear Select Sensor
73
Failed to Engage Gear
32 Switched System Voltage 56
Input Shaft Speed
Sensor
74 Failed to Synchronize
33 Battery Voltage Supply 57
Main Shaft Speed
Sensor
83 Shift Lever Missing
LIGHT BULB DATA
LIGHT BULB DATA
APPLICATION
PREVOST
PART NO.
TRADE OR
SAE NUMBER
POWER
(Watts, Amps or
Candle Power)
VOLTS
QTY
Hi-beam
562690
H5051
50 W
12
2
Low-beam
562689
H5062
40/55 W
12
2
Docking / Cornering
930319
H9415
37.5 W
12
4
Fog light
561882
H3 (Osram)
55 W
12
2
License plate light
930266
---
---
12
2
Front directional
930341
Del
0.6 A
12
6
Marker light (red)
930340
Del
0.6 A
12
2
Marker light (amber)
930341
Del
0.6 A
12
10
Identification light (red)
930334
Del
0.10 A
12
3
Clearance light (red)
930334
Del
0.10 A
12
4
Identification light (amber)
930337
Del
0.10 A
12
3
Clearance light (amber)
930337
Del
0.10 A
12
4
Hazard and marker light
561899
1157 NA
32/6 cp
12
2
Rear directional
561880
Hella
21 W
12
4
Stop (& center stop)
561880
Hella
21 W
12
5
Back-up
561880
Hella
21 W
12
4
Tail
561881
Hella
10 W
12
4
Engine compartment
560136
1003
15cp
12
2
136
