PREVOST H3-41 - Vehicle Dimensions and Capacities

TECHNICAL INFORMATION
DIMENSIONS AND
WEIGHTS
H3-41 H3-45
Overall length
(over bumpers)
41’ 7”
(12.7 m)
45' 8”
(13.9 m)
Overall width
102" (2.59 m)
Overall height
(normal ride height)
146 ¼" (3.715 m)
Wheelbase
(center of front axle
to center of drive axle)
267”
(6.782 m)
316 ¼"
(8.033 m)
Floor height from ground
63" (1.6 m)
Ground clearance
11" (280 mm)
Step height from ground
14" (356 mm)
Step height (other steps)
7” (178 mm)
Seats
48
56 - 58
Headroom
77" (1.956 m)
Entrance door opening
width
27" (686 mm)
Front overhang
76" (1,93 m)
Rear overhang
108 ½”
(2.757 m)
108 ¼"
(2.749 m)
Front track
84.4" (2.145 m)
Drive track
76.7" (1.949 m)
Rear track (tag axle)
83.6" (2.124 m)
Turning circle radius
(rigid axle suspension)
40' 4”
(12.3 m)
45’ 7”
(13.9 m)
Curb weight
35,535 lbs
(16 118 Kg)
36,860 lbs
(16 719 Kg)
Gross Vehicle Weight
Rating (G.V.W.R.)
52,060 lbs
(23 665 kg)
Front axle Gross Axle
Weight Rating
(G.A.W.R.)
16,500 lbs
(7 500 kg)
Drive axle G.A.W.R.
22,500 lbs (10 230 kg)
Tag axle G.A.W.R.
14,000 lbs (6 365 kg)
Note: Curb weight is given as an indication only
and is subject to vary from coach to coach,
mostly due to optional equipment.
The Gross Vehicle Weight Rating (G.V.W.R.)
and the Gross Axle Weight Rating (G.A.W.R.)
for front, drive and tag axles are listed on a
certification plate located on the L.H. control
panel in driver's section.
CAPACITIES H3-41 H3-45
Engine oil
(in crankcase)
41 US qts (39 l)
Engine oil
(in reserve tank)
8.4 US qts (8.0 l)
Fuel tank
(legal capacity equal
to 95% of volume)
235 US gal. (890 l)
CAPACITIES H3-41 H3-45
Cooling system 24 US gal. (91 l)
Allison transmission
(does not include
external circuit)
6 US gal. (23 l)
Eaton semi-
automatic trans.
13 US qts (12 l)
7-speed manual
transmission
6 US gal. (23 l)
6-speed manual
transmission
5 US gal. (19 l)
Differential oil
5 US gal. (19 l)
Power steering
reservoir
4 US qts (3.7 l)
A/C compressor oil
4.5 US qts (4.3 l)
Windshield washer
reservoir
5 US gal. (19 l)
Refrigerant
24.1 lbs (11 kg)
FUEL TYPE
ASTM specification ................................... D-975
Recommended grade ................................... 1-D
Acceptable grade .......................................... 2-D
WHEELS AND TIRES
Steel wheels ........................................ 9” X 22½”
Aluminum forged wheels..................... 9” X 22½”
Tires ............................................. 315/80 R 22.5
RECOMMENDED TIRE INFLATION
PRESSURE AT MAXIMUM COLD LOAD
The recommended tire inflation pressures are
given in the applicable documents supplied with
the vehicle. In addition, cold tire inflation
pressures are listed on the Department of
Transport (DOT) certification plate, affixed on
the wall behind the driver’s seat. For special tire
selection, a “PREVOST COACH SPECIAL
SPECIFICATION” chart is supplied with the
vehicle and is affixed next to the DOT
certification plate, located on the left wall close
to the driver’s seat.
116
