CONTROLS AND INSTRUMENTS
A low air pressure indicator LED (
bottom right
corner of gauge
) illuminates when the primary
air system pressure drops below 66 psi (455
kPa). An audible alert
signal also informs the
driver of low air pressure. Refer to Safety
Features and Equipment chapter for table of
audible alerts.
If the air pressure drops below
40 psi (276 kPa), the emergency brake applies
at full capacity.
Warning: Do not drive the coach when air
pressure is low.
Secondary System Air Pressure (Front)
06227
Indicates the secondary air
system
pressure. The
normal operating pressure
is from 95 to 125 psi (655 to
860 kPa).
A low air pressure indicator LED (
bottom right
corner of gauge
) illuminates when the
secondary air system pressure drops below 66
psi (455 kPa). An audible alert
signal also
informs the driver of low air pressure. Refer to
Safety Features and Equipment chapter for
table of audible alerts. If the air pressure drops
below 40 psi (276 kPa), the emergency brake
applies at full capacity.
Warning: Do not drive the coach when air
pressure is low.
VEHICLE CLEARANCE INFORMATION
12' 4"
3.76 m
06447
Safe vehicle clearance height is 12’4" (3.76 m).
Caution: vehicle clearance is higher when the
ventilation hatch is open, Hi-Buoy is selected or
if additional equipment is installed on the roof.
TELLTALE PANEL
TELLTALE PANEL 06444
Some telltale lights described bellow appear on
the telltale panel only if the corresponding
optional equipment is installed on the vehicle.
Wheelchair Lift Enabled
06295
Illuminates when the wheelchair lift
is enabled.
Wheelchair Lift Door Ajar
Illuminates when the wheelchair lift
compartment door and/or the
wheelchair access door is open.
06299
The parking brake is activated
when this door is open. Refer to
Other Features chapter.
Warning: Opening the door at a speed under
5 mph (8 km/h) will activate the parking brake
and sound an audible alert..
Lavatory Door Locked
06375
Illuminates when the lavatory door
is locked
