COACH INTERIOR
PNEUMATIC ISRI SEAT
PNEUMATIC DRIVER’S SEAT 18385
Armrest (1)
Rotate control knob to select desired arm-resting
angle. When not in use, raise armrest parallel
with backrest.
Seat Cushion (2)
Provides optimum comfort and support for any
driver size. Adjustable to 50mm length.
Fore-and-aft (3)*
Pull handle up and slide seat forwards or
backwards to adjust distance between seat and
dashboard.
Isolator (4)
Reduces horizontal vibration, ensuring smooth
ride.
Backrest (5)
Lift lever to select proper adjustment angle of
backrest.
Air Side Bolster (6)
Offers desired side support to avoid body side-
way.
Air Lumbar (7) (8)
Provides back support with upper and lower
settings, ensuring comfort during lengthy sitting.
Air Height Adjustment (9)
Moves seat up or down independently of other
seat settings. 100mm total travel.
Adjustable Seat Recline (10)
Allows easy adjustment of four-setting
inclination.
Adjustable Shock Absorber (11)
Choose stiff or soft ride infinitely.
Quick Air Release (12)
Exhausts all air from suspension, allowing for
easy entry/exit. Returns seat to previous
position.
SAFETY BELTS
The driver’s seat is equipped with a retractable
safety belt as required by State, Provincial and
Federal regulations. To fasten, pull seat belt out
of the retractor and insert the latch plate into the
buckle until it clicks. No special adjustment is
required since the reel device is self-adjusting.
If seat belt operation becomes defective, report
to a Prevost Car service center immediately.
SEATBELT 18028
Note: The safety belt must be pulled out slowly
and continuously, otherwise it will lock the reel
before the latch plate reaches the buckle. If this
happens, allow the belt to retract completely and
repeat the procedure correctly.
18
