PREVOST H3-41 User Manual

COACH EXTERIOR
000
000
1 2 3 4
5
6
7
8 6 6 109
14
15
12
13
11
16 6 6 1918 7 2066
6
17
H3-45 EXTERIOR VIEW (TYPICAL) 18314
1.
Engine air intake
11.
Back up camera (optional)
2.
Engine compartment curb-side door
12.
110/120 volt connector, for block heater
3.
Wheelchair access door (optional St. & St. lift)
13.
Engine compartment rear door
4.
Main power compartment
14.
Rear-view mirror
5.
Wheelchair access door (optional Ricon lift)
15.
Reclining front bumper
6.
Baggage bay door
16.
Front service compartment
7.
Fuel filler door
17.
Driver’s power window
8.
Condenser compartment
18.
Evaporator compartment
9.
Entrance door control switch
19.
Rear electrical compartment
10.
Entrance door
20.
Radiator door
