COACH INTERIOR
A telltale light on the dashboard will illuminate to
inform the driver when the lavatory is occupied.
A night-light is permanently lit in the lavatory
when the ignition switch is in the ON position.
If emergency assistance is required, the lavatory
occupant can actuate a buzzer that will sound in
driver's area. The buzzer push-button and
instruction label are located on the wall of the
lavatory.
The lavatory has it's own ventilation system that
operates continuously when the ignition switch is
in the "ON" position.
The fresh water tank may be equipped with an
immersion heater that is supplied by the 110/120
volt connector for the engine block heater.
LAVATORY 23035
1. Cleaning cabinet;
2. Mirror;
3. Paper towel dispenser;
4. Toilet paper roll;
5. Grip handle;
6. Faucet;
7. Flush button;
8. Emergency call button;
9. Waste basket.
24
