Fault Messages
261
DP FIFO Busy* Yes There is a timing problem
in the Engine Controller
firmware.
1. Cycle power. Run the print
job again. If the message
appears, download the
emulation software again.
2. Cycle power. Run the print
job again. If the message
appears again, contact your
authorized service
representative.
1
DRVR CIR BAD* No Driver Circuit Bad. The
hammer coil count test
failed.
Contact your authorized service
representative.
1
E00 EXE @ ADDR0
See User Manual
Yes An illegal or unsupported
instruction was attempted
in the application
program.
1. Cycle Power. Run the print
job again. If the message
appears, load the latest
emulation software.
2. Cycle power. Run the print
job again. If the message
appears, record the display
message and send it to your
next higher support facility.
E01A TYPE 0x40
See User Manual
Yes An illegal or unsupported
instruction was attempted
in the application
program.
1. Cycle Power. Run the print
job again. If the message
appears, load the latest
emulation software.
2. Cycle power. Run the print
job again. If the message
appears, record the display
message and send it to your
next higher support facility.
E01B TYPE 0x60
See User Manual
Yes An illegal or unsupported
instruction was attempted
in the application
program.
1. Cycle Power. Run the print
job again. If the message
appears, load the latest
emulation software.
2. Cycle power. Run the print
job again. If the message
appears, record the display
message and send it to your
next higher support facility.
Table 15. LCD Message Troubleshooting Table
Displayed Message
Can User
Correct?
Explanation Solution
To Next Page
