Priva Compass - Technical Specifications

Technical specifications
Groscale
Groscale 100 kg
Product
• 1 weighing indicator (part number 3771140)
• 2 weighing platform 50 kg
Groscale 200 kg
• 1 weighing indicator (part number 3771140)
• 2 weighing platform 100 kg
Groscale 400 kg
• 1 weighing indicator (part number 3771140)
• 4 weighing platform 100 kg
Weighing platform
3771142 (weighing platform for 50 kg)
3771147 (weighing platform for 100 kg)
Part number
0.05% Full Scale minimumAccuracy
10 ppm of placed weight /°CDrift at output signal
23 ppm of weight range /°CDrift at zero point
Load cell interface
1 - 4Number of load cells
415 Ohm ±10%Load cell impedance
4,4 VACAgitation voltage
-0,1 - 2,4 mV/VInput voltage range
<0.1 μV/div, intern 0.01 V/divSensitivity
<8 ppm / °CDrift
Analog outputs
0 - 5300 mVOutput range
0 - 5000 mVWork area
1 mV / LSBResolution
0,5% Full ScaleAbsolute accuracy
0,5 LSBRelative accuracy
500 OhmOutput impedance
Power supply
20 - 38 VDC (power supply galvanically separated)DC
24VAC ± 10% (power supply galvanically separated)AC
< 4WPower consumption
Temperature range
15 - 35°CWork area
0 - 50°CWork range
Overall system performance
0,1 % Full Scale. minimalMeasuring accuracy
4000 parts Full ScaleAbsolute accuracy data transfer (2 outputs)
50000 parts Full ScaleRelative accuracy data transfer (2 outputs)
Installing Priva Compass - 00.014118
