Maintenance of wind direction sensor
Check the wind direction sensor regularly for pollution and clean it if necessary. Pollution may cause
the wind vane to be obstructed. Clean the unit with a damp cloth and a little mild detergent if required.
Do not use aggressive cleaning agents or abrasives.
Make sure that no moisture, dirt or dust enters the housing when opening the Wind direction
sensor. This can negatively impact the measurement.
Specifications
Wind direction sensorArticle description
3779215Article number
optical or magneticMeasurement principle
0 – 359°Wind direction
1°Resolution
1°Measuring error
20Measurements/sec
Single endedOutput signal
200 - 3440 mVOutput range
18 – 40 VDCSupply voltage
15 mA (max)Power consumption
Continuous 24 VAC
Discharges 900 V/100 nF
Short circuit-proof output
Protection
-40 – +80 °CAmbient temperature
The output signal is divided across seven measurement zones, including two defect zones. See the
table below.
Wind directionOutput voltage (mV)
Defect0 – 200
North – East200 – 920
East – South920 – 1640
South – West1640 – 2360
West – North2360 – 3080
North – North-east3080 – 3440
Defect3440 – 4096
