Connecting hardware
Overview of a Priva Blue ID C-Line system
A Priva Blue ID C-Line system consists of one controller and one or more modules with I/O. A system
may consist of the controller alone, since the controller is equipped with various inputs and outputs.
If there is a need for more inputs and outputs, the system may be expanded with additional modules.
All modules are connected to each other via the I/O bus.
Connections
The hardware is equipped with the connections described in the table below. A picture of the
connections is provided and other details are described later in this chapter.
NumberConnectingHardware
Priva Blue ID C-Line hardware
1
1
1
4
1
12
8
6
8
1
1
Power supply voltage (24 VDC)
I/O bus out
RS485 port
Ethernet port
Shield (for Ethernet ports)
Digital inputs
Universal inputs
Analogue outputs
Relay outputs
USB host
USB device
C4 C-MX34 controller
1
2
12
8
6
8
Power supply voltage (24 VDC)
I/O bus in and out
Digital inputs
Universal inputs
Analogue outputs
Relay outputs
C-Line MX34 module
2
6
I/O bus in and out
Universal inputs
C-Line UI8 module
2
6
I/O bus in and out
Relay outputs
C-Line DOR6 module
For UL916 / CSA C22.2 No. 205: use UL-listed or CSA-certified wiring and crimp-on terminals.
Connectors
To make connections, use the supplied connectors or the optionally available right-angled screw
connectors. Right-angled screw connectors are supplied as a set for a module. The set contains the
right-angled screw connectors that are needed for the connectors on the module concerned.
Connecting with flexible wire
When using flexible wire, always use a crimp-on terminal.
With crimp-on terminals
1. Strip the wire:
• If using single crimp-on terminals: strip 10 mm off.
• If using double crimp-on terminals: strip 12 mm off.
2. Fit the crimp-on terminal.
