Priva Compass - EC-DSS Interface; EC-DSS Interface Operation

The use of 5 dosing channels with GevaSol valves requires at least 100VA. Therefor the
graphic above includes a 300VA transformer. The 24 VAC transformer from the Compass
cabinet can be used, but this means there is no output power available for other components.
Dosing Channel Driver power supply cable
ConnectionFunctionName
to 24 VAC of external power supply ¹24 VAC24VAC
to 0 VAC of external power supply ¹0 VAC0VAC
¹ Use a transformer of at least 24 VAC 100VA; 300VA is desirable.
Cables from Dosing Channel Driver to Compass
ConnectionFunctionName
to relay output (voltage free) of Priva Blue ID
module
start dosing cycleENABLE
to AO of Priva Blue ID modulesensor signalAI-1 …AI-5
to FG of Priva Blue ID moduleGNDGND
Cable from Dosing Channel Driver to dosing channel
ConnectionFunctionName
to 0 VAC to TRIAC of dosing channel0 VACValve1 … Valve5
to 24 VAC to TRIAC of dosing channel24 VAC24VAC1…
24VAC5
Specifications Dosing Channel Driver
General
Dosing Channel Driver for Priva dosing channelsModule article description
3770170Module article number
5Number of outputs
130 x 160 x 70 mm (5.1 x 6.3 x 2.8 inch)Dimensions (XYZ)
1.9 WMaximum power consumption
clicks onto DIN railInstallation
PVC V-0 (UL94)Housing material
pluggable terminal blockConnector type for power supply and I/O
solid:: 0.2 … 2.5 mm² (25 … 14 AWG)
flexible with ferrule connector: 0.2 … 2.5 mm² (25 … 14 AWG)
flexible with double ferrule connector: 0.2 … 1.5 mm² (25 … 16
AWG)
Permitted core cross section area
solid: 10 mm (0.39 inches)
flexible with ferrule connector: 10 mm (0.39 inches)
flexible with double ferrule connector: 12 mm (0.47 inches)
Strip length/connector length (terminal block)
Digital solid-state outputs (TRIAC)
0 … 30 VACSwitching voltage
0 … 2.5 A (RMS)Load current
3.15 AT fuse (per channel)Overvoltage protection
output protected against overload (not self-restoring)
power supply input protected against overload (self-restoring)
Protection
10 mMaximum length of output cable
TRIACSwitch type
0.2 HzMaximum switching frequency
0.1 … 5 sDuty cycle
Indication
• red LEDs for status of outputs
• green flashing LED for status of the module
• green LED for status of the enable input
89Installing Priva Compass - 00.014
Dosing Channel Driver
