Priva Compass - Technical Specifications - Ph Sensor

Technical specifications – pH sensor
pH sensor (max. 10.0 bar)Article description
3779046Article number
glassHousing
77 mmLength of sensor
Ø 12 mm (Ø 15 mm with protective cover)Diameter of sensor
pH electrode for H
+
ions
Measurement principle
59 mV/pH (in operating range 4 .. 7 pH at 25 ˚C)Discrimination
4 .. 7 pHOperating range (measured values satisfy
the specified accuracy)
3 .. 14 pHRange (sensor produces measured values)
± 0.1 pH (in operating range 4 .. 7 pH at 5 .. 30 ˚C)Accuracy (after calibration)
coax, Ø 2.5 mm, length 3 mCable
BNCConnector
Installing Priva Compass - 00.01486
Priva
