Priva Compass - Specifications

Jumper FJumper EJumper DJumper CJumper BJumper ASensor
radiation
factor max
Sensor
radiation
factor min
X-X--X248.03245.32
--X--X245.32242.64
XX---X242.64240.03
-X---X240.03237.49
X----X237.49235.00
-----X235.00232.32
XXXXX-232.32229.70
-XXXX-229.70227.37
X-XXX-227.37225.08
--XXX-225.08222.83
XX-XX-222.83220.63
-X-XX-220.63218.47
X--XX-218.47216.37
---XX-216.37214.28
XXX-X-214.28212.24
-XX-X-212.24210.25
X-X-X-210.25208.30
--X-X-208.30206.37
XX--X-206.37204.47
-X--X-204.47202.62
X---X-202.62200.81
----X-200.81198.96
XXXX--198.96197.14
-XXX--197.14195.42
X-XX--195.42193.73
--XX--193.73192.06
XX-X--192.06190.42
-X-X--190.42188.82
X--X--188.82187.24
---X--187.24185.68
XXX---185.68184.14
-XX---184.14182.64
X-X---182.64181.17
--X---181.17179.70
XX----179.70178.27
-X----178.27176.86
X-----176.86175.47
X = connect jumper
- = disconnect jumper
Specifications
General
Meteorological station interface WI2Article description
3771351Article number
24 VAC ±15 %Supply voltage
300 mA, 7VAPower consumption (Weather interface WI2 only)
screwConnector terminals
22 x 16 x 10 cmDimensions (L x W x H)
Installing Priva Compass - 00.01462
Priva
