General specifications of Priva Blue ID C-Line
controllers and modules
RequirementsSystem power supply
The system power supply for the controllers and Mix I/O modules must meet the following requirements.
24 VAC ± 25%; 50/60 Hz ± 5 %
24 VDC ± 10%
Output voltage
double insulation between input and outputInsulation
for UL916, CSA C22.2 No. 205: UL listed / CSA certified Class 2 extra
low output voltage power supply
Type of power supply
Housing
IP20 (IEC 60529)IP code
V-0 (UL 94)Flammability class
7Recycle code
housing: white (RAL9001) and blue (NCS S 1560-R90B)
connections and connectors: black (RAL9011)
Colour
open type equipment for:Type of device
• indoor use only
• pollution degree 2 environment
Installation and connection
in control panel:
Installation
• accessible to authorised personnel only
• can be clicked onto horizontally or vertically positioned DIN
rail. DIN rail installed directly on a mounting plate or floating
with respect to the mounting plate
in DIN 43870 distribution box
35 x 7.5 (1.38 x 0.30 inches) or 35 x 15 mm (1.38 x 0.59 inches)
(height x depth), in accordance with IEC 60715
Type of DIN rail
pluggable terminal block
screw connectors (optional)
Connector type for power supply and I/O
solid:: 0.2 … 2.5 mm² (25 … 14 AWG)
flexible with ferrule connector: 0.2 … 2.5 mm² (25 … 14 AWG)
flexible with double ferrule connector: 0.2 … 1.5 mm² (25 … 16
AWG)
Permitted core cross section area
solid: 10 mm (0.39 inches)
flexible with ferrule connector: 10 mm (0.39 inches)
flexible with double ferrule connector: 12 mm (0.47 inches)
Strip length/connector length (terminal block)
8 mm (0.31 inches)Strip length/connector length (screw connector)
labelling with an explanatory abbreviationIdentification of connections
3 m (9.84 ft)Maximum length of I/O bus cable between
modules
20 m (65.62 ft)Maximum length of I/O bus (total, including
modules)
123Installing Priva Compass - 00.014
General specifications of Priva Blue ID C-Line controllers and modules
