Priva Compass - Expanding the EC-DSS Interface; Technical Specifications - EC-DSS-Interface

EC-DSS interface cable to Compass
ConnectionFunctionName
UI of Priva Blue ID module
Add a pull-down resistor (100kΩ) to
GND for cable break detection.
sensor signal sensor 1MB1
FG of Priva Blue ID moduleGNDGND
UI of Priva Blue ID module
Add a pull-down resistor (100kΩ) to
GND for cable break detection.
sensor signal sensor 2MB2
FG of Priva Blue ID moduleGNDGND
0 VAC of power supply0 V0 VAC
24 VAC of power supply24 V24 VAC
Expanding the EC-DSS interface
1. Unscrew and open the interface.
2. Screw a connection board 9943 to the bottom plate.
3. Insert an EC interface board 8658 into the connector of the connection board 9943.
4. Screw the interface closed.
Technical specifications - EC-DSS-interface
EC-DSS-interfaceArticle description
3771051Article number
plasticHousing material
180 x 165 x 135 mmDimensions H x L x W (without grommet)
on EC-interface board 8658:
Connections
• 24 VAC input power supply
• 2 inputs for EC or DSS
• 2 analog outputs
24 VACSupply voltage
0 … 35 °CAmbient temperature
