Priva Compass - Weather Interface WI2; WI2 Purpose and Installation

The sensors are supplied with 10-metre screened cable. It is recommend that you do not
shorten these cables when mounting the sensors. Coil the remaining length of cable or leave
a loop; this will simplify any future expansion of the Meteorological station with additional
crossbars of mast sections.
Mounting the clamping blocks
4. Bolt for clamping block1. Upper mast section
5. Nut for clamping block2. Lower mast section
6. Socket-head screw3. Clamping block
Maintenance of Meteorological station
Check the condition of the mast section's fastening bolts at least once a year (the bolts must not be
rusted).
Meteorological station specifications
two supports
two mast components
clamping blocks
wall brackets
installation material
Construction
aluminium (AlMg1)Supports material
Al 50 StMast component material
aluminiumClamping block material
galvanized steelWall bracket material
500 x 700 x 3200 mmDimensions (l x w x h)
Installing Priva Compass - 00.01456
