Overview of connecting sensors and systems
The following sensors and systems can be used in a Compass system and can be connected to the
Compass cabinet.
Connect toArticle numberSensor, interface or system
RS485 input of Priva C43779240Weather station WSC11
universal input of a Priva Blue ID module3771351Weather interface WI2
24 VDC power supply
24 VAC power supply
3771009Meteorological station with:
Weather interface WI23779203Wind speed sensor
Weather interface WI23779204Outside temperature sensor
Weather interface WI23779206Rain sensor
Weather interface WI23779215Wind direction sensor
Weather interface WI23779205Linear light sensor LS2WI
0-50 mV
universal input of a Priva Blue ID module3779213Linear light sensor LS2 0-5 V
24 VDC power supply
24 VAC power supply
Weather interface WI23779207Solari / radiation sensor
potential-free contact, connect directly to the universal
input of a Priva Blue ID module
3779000Snow sensor
24 VAC power supply
4 … 20 mA, connect directly to the universal input of a Priva
Blue ID module
3779219Air humidity sensor
universal input of a Priva Blue ID module
24 VAC power supply
universal input of a Priva Blue ID module3771051EC-DSS interface ¹
24 VDC power supply
24 VAC power supply
EC-DSS interface3771052EC sensor, short, with NTC 1
kΩ/25°C (inline)
EC-DSS interface3771041EC sensor, long, with NTC 1
kΩ/25°C (angled)
EC-DSS interface3779224Drain sensor system
universal input of a Priva Blue ID module3771056pH interface
24 VDC power supply
24 VAC power supply
pH interface3779046pH sensor
universal input of a Priva Blue ID module3779024Priva Measuring Box T+RH ²
24 VDC power supply
24 VAC power supply
universal input of a Priva Blue ID module3779027Priva Measuring Box T
universal input of a Priva Blue ID module3795044Guardian CO2 monitor
90 … 260 VAC power supply (50 - 60Hz)
universal input of a Priva Blue ID module3779013Water temperature sensor
universal input of a Priva Blue ID module3779016Soil temperature sensor
universal input of a Priva Blue ID module3771140Priva Groscale weighing system
24 VDC power supply
24 VAC power supply
analogue output of a Priva Blue ID module3770170Dosing Channel Driver
24 VAC power supply
¹ connections for 2 EC sensors or 2 Drain sensor systems
² temperature sensor and relative air humidity sensor are connected separately
