Priva Compass - Specifications

Checking by dealer
The Linear light sensor is delivered pre-calibrated. Have the Linear light sensor checked by your
dealer once a year to guarantee correct and accurate measurement.
Specifications
Linear Light Sensor LS2
Linear Light Sensor LS2Article description
3779213Article number
photodiodeMeasurement principle
525 ... 1100 nm (50 % spectral sensitivity points)Spectrum
850 nmPeak response
60°Half angle
33 mV/kluxSensitivity
0 ... 150 kluxMeasurement range
0 ... 5 V (not electrically isolated)Output range
21.6 .. 26.4 VDCSupply voltage
short-circuit proof
24 VAC continuous
discharges 900 V/100 nF
Protection
-40 … 80 °CAmbient temperature range
Linear Light Sensor LS2WI (0 … 50 mV)
Linear Light Sensor LS2WI (0 … 50 mV)Article description
3779205Article number
photodiodeMeasurement principle
525 … 1100 nm (50 % spectral sensitivity points)Spectrum
850 nmPeak response
60°Half angle
180 … 340 µV/klux (refer to calibration certificate)Sensitivity
0 … 160 kluxMeasurement range
0 … 50 mV (depending on sensitivity, refer to calibration certificate)Output range
short-circuit proof
24 VAC continuous
discharges 900 V/100 nF
Protection
-40 … 80 °CAmbient temperature
Installing Priva Compass - 00.01466
Priva
