Analogue inputs
0 … 10 VDCInput voltage range
2 VMinimum input voltage for pulse control
input protected against overvoltage up to 30 VDC and 30 VACProtection
100 mMaximum length of input cable
0.5 mm² (0.8 mm)Minimum core cross section
Digital inputs
0 … 24 VAC
0 … 24 VDC
Input voltage range
input protected against overvoltage up to 30 VDC and 30 VACProtection
100 mMaximum length of input cable
0.75 mm² (1 mm)Minimum core cross section
Housing
IP20 (IEC 60529)IP code
V-0 (UL 94)Flammability class
jet black (RAL9011)Colour
open type equipment for:Type of device
• indoor use only
• pollution degree 2 environment
Installation and connection
in control panel:
Installation
• accessible to authorised personnel only
• can be clicked onto horizontally or vertically positioned DIN
rail.
35 x 7.5 (1.38 x 0.30 inches) or 35 x 15 mm (1.38 x 0.59 inches)
(height x depth), in accordance with IEC 60715
Type of DIN rail
Environment
0 … 50 ºC (32 … 122 °F)Permitted temperature inside control panel of a
working system
-20 … 70 ºC (-4 … 158 °F)Permitted temperature during transport and
storage
10 % … 95 % (niet-condenserend)Permitted ambient relative humidity
IEC 61131-2Shock and vibration resistance
IIInstallation category
Legislation and standards
• Low Voltage Directive 2006/95/EC:
• EN 61010-1 (measurement and control equipment)
• EN 61010-2-201 (measurement and control equipment)
• EMC Directive 2004/108/EC:
• EN 61326-1 (measurement and control equipment)
• EN 61000-6-2 (generic immunity standard)
• EN 61000-6-3 (generic emission standard)
• RoHS directive 2011/65/EU
Europe
