Specifications of Priva Blue ID C-Line DOR6 Relay output module
General
Priva Blue ID C-Line DOR6 Relay output moduleModule article description
5215001Module article number
140 x 63 x 62 mm (5.6 x 2.5 x 2.5 inches)Dimensions (XYZ)
3.5 TE (HP) (1 TE = 18 mm (0.71 inches))Width according to DIN 43880
53.5 mm (2.11 inches)Mounting depth for DIN 43870 distribution box ¹
0.18 kg (0.40 lb)Weight
24 VDC: 1.2 WMaximum power consumption
1.2 WTypical power dissipation ²
4,380,000 hoursMTBF ³
clicks onto DIN rail
can be mounted in DIN 43870 distribution box
Installation
mixture of polycarbonate and ABSHousing material
TPE (synthetic rubber)Button material
6, consisting of
5 with normally open contact
1 with changeover contact
Number of relay outputs
¹ measured between the front of the DIN rail and the rear of the cover plate.
² Dissipation under the following conditions:
- I/O load of 50%
- 50% of the LEDs on
³ The MTBF is calculated according to the Telcordia SR-332 standard Issue 3 under the following conditions:
- ambient temperature: 35 … 50°C (95 … 122 °F)
- supply voltage: 24 VDC
- time in operation per day: 24 hours
- reliability level: 60%
Specifications of outputs
For the specifications of the outputs, see Specifications of inputs and outputs (page 131)
