Priva Compass - Page 86

T-pieces saddle fitting - lines with a metric diameter
Saddle fitting for flow sensor GF2536-P0, metricArticle description
750479750478750477Article number
110
(DN100)
90
(DN80)
75
(DN65)
Line diameter, external (mm)
7.34 .. 73.44.90 .. 49.03.46 .. 34.6
Measuring range (m
3
/hr) at
a flow rate of 0.3 .. 3 m/s and
lines of pressure class PN16
4.8067.2819.787K-factor (pulses per litre)
0.2080.1370.102Litre per pulse (1/K)
Saddle fitting for flow sensor GF2536-P1, metricArticle description
750467750466750483750482Article number
225
(DN200)
160
(DN150)
140
(DN125)
125
(DN115)
Line diameter, external (mm)
33.9 – 33910.5 .. 10514.6 .. 14611.3 .. 113
Measuring range (m
3
/hr) at
a flow rate of 0.3 .. 3 m/s and
lines of pressure class PN16
1.142.603.4464.317K-factor (pulses per litre)
0.8770.3850.2900.231Litre per pulse (1/K)
T-pieces - lines with an imperial diameter
T-piece GF for flow sensor GF2536-P0, imperialArticle description
750783750782750781Article number
432.5Line diameter, internal (")
8.76 .. 87.64.93 .. 49.33.42 .. 34.2
Measuring range (m
3
/hr) at
a flow rate of 0.3 .. 3 m/s and
lines of pressure class
comparable with PN16
3.9647.0411.359K-factor (pulses per litre)
0.2520.1420.088Litre per pulse (1/K)
T-piece GF for flow sensor GF2536-P1, imperialArticle description
750784Article number
6Line diameter, internal (")
19.7 .. 197
Measuring range (m
3
/hr) at
a flow rate of 0.3 .. 3 m/s and
lines of pressure class
comparable with PN16
2.199K-factor (pulses per litre)
0.455Litre per pulse (1/K)
For different configurations, a K-factor calculator is available at www.gfsignet.com.
Installing Priva Compass - 00.01484
