99
SPECIFICATIONS
HDMI
All HDMI Per HDMI v1.3a Specications
Type Repeater
FM Tuner Sections
Tuning Range 87.5 to 108.0 MHz
Usable Sensitivity (IHF, 98.1 MHz) 11 dBf Mono
Sensitivity (50 dB quieting, 98.1 MHz) 16 dBf Mono, 38 dBf Stereo
S/N Ratio (65 dBf, 98.1 MHz) 78 dB Mono, 72 dB Stereo
Freq. Response (Mono or Stereo) 20 Hz to 15 kHz +/- 3 dB
Separation (@ 1 kHz, 65 dBf) > 40 dB
THD (1 kHz, 65 dBf, 98.1 MHz) 0.15% Mono, 0.3% Stereo
Capture Ratio (45 dBf) 2.0 dB
AM Rejection Ratio 50 dB
Alternate Channel Selectivity 70 dB
AM Tuner Sections
Tuning Range 530 to 1710 kHz
Sensitivity (20 dB Quieting, 1000kHz loop antenna) 500 mV/m
Selectivity (@ S/N 20dB, +/- 10 kHz) 30 dB
S/N Ratio (400 Hz, 10 mV/m Input @ 1000 kHz, 30% Mod.) 45 dB
THD (400 Hz, 10 mV/m Input @ 1000 kHz, 30% Mod.) 0.8%
Selectivity +/- 10 kHz, >25dB
Image Rejection (1400 kHz) 34 dB
Control Sections
IR Control
IR 1 & 2 IN 5 V p-p Active High, with Carrier
IR OUT 5 V p-p Active High, Stripped Carrier (4V with 270 Ohms Loading)
Trigger OUT
Trigger Outputs (0 to 12 V DC) 12 V @ 10 mA, 9.0V @100mA
General
Power Consumption 120V Version
Standby 2.0 Watts
No signal (idle) 85 Watts
At 1/8 Rated Power (10 Watts/Channel, 8Ω) 570 Watts
Rear Panel Marked Line Ratings 120 VAC, 60 Hz, 4.2A
Switched AC Outlet Rating 120 VAC, 100 Watts, 1 Amp Max
Dimensions
17-1/8” W x 5-7/8” H* x 14-3/4” D
* 6-1/2” H, including feet
Weight
31 lbs
